LIROS mooring rope PORTO eye spliced docklineBreaking load: depends on line diameter (See table below. t (reduction in breaking load by 20% due to the eye splice already included)Diameter ø: 10 mm - 18 mmLengths: 6 m - 30 m (different lengths on request)Colours: navy blue, black, silver grey, white-blackConstruction: cover and core, polyester double braid, braid on braidMaterial: 100% polyester (PES) Core: high-strength polyester, braided Cover / sheath: polyester, braided, twisted yarn for enhanced stretchBraid up to 10 mm diameter: 16-plait braidBraid from 12 mm diameter: 20-plait braidedRight end: 40 cm eye spliceLeft end: whipping knotElasticity / stretch: high elasticity due to the special twist construction, elongation at working load > 15 % (4 out of 5 points)Grip: pleasant, very handy and permanently soft - no hardening due to weathering (4 of 5 points)Spliceability: easy to splice (4 of 5 points)Abrasion resistance: extremely resistant to chafing (5 of 5 points)UV resistance: very resistant to UV radiation (5 of 5 points)Floatability: no, does not floatConclusion: very high quality, elastic mooring line, comes with by highest resistance to abrasion and sunlight DiameterBreaking LoadBreaking LoadRecommended up to … displacementRecommended up to … length overallRecommended up to … length overall ø 10 mm1760 daN1.79 t1 t8 m27 ft ø 12 mm2320 daN2.36 t2 t10 m33 ft ø 14 mm2960 daN3.02 t5 t12 m40 ft ø 16 mm3920 daN4.00 t12 t14 m46 ft ø 18 mm4240 daN4.32 t20 t18 m60 ft
