With this AURIX™ 2G TC397XA 3.3V ADAS evaluation board customers can connect through a dedicated Radar Interface and quickly start to develop, evaluate and test a full radar application. The TC397XA is mounted on a socket so that it can be easily changed, making it particularily suitable for early project development. A downloadable User Manual helps with the installation, use and configuration of the board and includes the schematics and the layout. ( See Documents section ) Summary of Features: Infineon’s TC397 ADAS AURIX™ 2G Controller in LFBGA-292_ADAS Package FlexRay™ Transceivers High Speed CAN Transceivers (CAN-FD capable) USB to UART bridge Ethernet Gigabit PHY Serial Eeprom LIN Transceiver Crystal 20MHz (default) or External Clock USB miniWiggler JDS for easy debugging 8 Low Power Status LEDs 8-DIP switches for configuration access to all pins of controller 100mm x 160mm (EURO-Board) Connectors : The TC3X7 ADAS TriBoard offers a wide variety of connectors: Standard power connector Micro USB connector for ASC Interface (ASC0) and miniWiggler RJ45 connector for Ethernet 16-pin header for JTAG interface (OCDS) 3 x 10-pin header for DAP, DAPE and DAP_SCR (DAPE only usable on Emulation Device) 10pin (2x5) Header for LIN Transceiver (LIN) 2 x 10pin (2x5) Header for CAN High Speed Transceiver (CAN0 and CAN1) 2 x 10pin (2x5) Header for FlexRay™ (ERAY-A and ERAY-B) 2 x 60pin (2x30) high speed connector for MMIC/RIF four 80-pin connectors (male) + four 80-pin connectors (female) with all I/O signals optional ETK connector optional 6pin (IEEE1394) Socket for HSCT optional Aurora connector (only with Emulation Device) Components: Infineon’s Multi Voltage System Supply TLF3068xQVS01 Three LEDs to validate power supply (5Volt / 3,3 Volt / 1,25 Volt) LED indicating safe state signal from TLF3068x (only with TLF30684) LED indicating /HDRST (ESR0) active state LED indicating activ miniWiggler JDS LED switched via DAS software 2 x Infineon’s FlexRay™ Transceiver TLE9
