Gyártói típuskód S203P-4Gyártó ABBGyártói cikkszám 2CDS283001R0338Kioldási karakterisztika ZEnergiabehatárolási osztály 3Beépítési mélység 44 mmÉpítési szélesség 52,5 mmÉpítési méret 3Szennyeződési fok 2Védettség IP20Frekvencia 50 HzFeszültség fajtája ACNévleges megszakító képesség (EN 60898) 25 kANévleges feszültség 440 VNévleges áram 4 APólusszám 3Túlfeszültség-kategória 3 S203P-Z4General InformationExtended Product Type:S203P-Z4Product ID:2CDS283001R0338EAN:4016779593786Catalog Description:Miniature Circuit Breaker - S200P - 3P - Z - 4 ALong Description:System pro M compact S200P miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 25 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200P comply with IEC/EN 60898-1, IEC/EN 609 47-2, UL1077 and CSA 22.2 No. 235, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200P to save 50% space.CategoriesProducts » Low Voltage Products and Systems » Modular DIN Rail Products » Miniature Circuit Breakers MCBsS203P-Z4 - image 0+AccessoriesTechnicalStandards:CSA 22.2 No. 235IEC/EN 60947-2UL 1077Number of Poles:3Number of Protected Poles:3Tripping Characteristic:ZRated Current (In):4 ARated Operational Voltage:acc. to IEC 60898-1 400 V ACacc. to IEC 60947-2 400 V ACRated Voltage (Ur):400 V ACPower Loss:7.8 Wat Rated Operating Conditions per Pole 1.6 WRated Insulation Voltage (Ui):acc. to IEC/EN 60664-1 440 VRated Frequency (f):50 / 60 HzRated Short-Circuit Capacity (Icn):(230 V AC) 12.5 kA(400 V AC) 12.5 kARated Ultimate Short-Circuit Breaking Capacity (Icu):(230 V AC) 25 kA(400 V AC) 25 kARated Service Short-Circuit Br
