Features Water cooled Heat exchangers use fresh or seawater for air and oil cooling Nitrox membrane system with (2) O2 analyzers CompAir rotary screw compressor Hankison LP Filtration for Membrane System Refrigerated air dryer for long filter life Manual back pressure regulator control for O2% adjustment Automatic condensate drains Automatic shutdown for high pressure and high temperature Compressor pressure is modulation controlled Marine grade aluminum frame with stainless steel motor plate Soft start Advantages Simplest, most cost-effective nitrox system available Supply LP nitrox containing up to 40% oxygen (EANx40) Lower costs, less hassles and hazards compared to O2 partial-pressure blending Systems to fit most HP compressors Water cooling and compact size allow installation below deck in hot engine rooms with limited space Marine grade heat exchangers with replaceable zinc annodes Soft start for reduced amperage draw on start-up Options Nitrox Manager Low/high O2 alarm or shutdown Low/high CO alarm or shutdown Low/high CO2 alarm or shutdown Remote operation capability Frequency drive for easy start Membrane system mounted to frame Sound shield Specifications Model LP280ME LP300ME LP450ME LP600ME LP750ME LP1000ME Horsepower 10 hp · 7.5 kW 10 hp · 7.5 kW 15 hp · 11.2 kW 20 hp · 15 kW 25 hp · 19 kW 30 hp · 22 kW 208-230 V / E1 / 60 Hz 50 A7060.1ME-EK76-WC N/A N/A N/A N/A N/A 208-230 V / E3 / 60 Hz¹ N/A 33A7060.2ME-EK76-WC 47A7061.2ME-EK76-WC 63A7062.2ME-EK76-WC 64A7063.2ME-EK100-WC 80A 380-415 V / E3 / 50 Hz N/A 18A7060.6ME-EK76-WC 22A7061.6ME-EK76-WC 29A7062.6ME-EK76-WC 33A7063.6ME-EK100-WC 40A 440-480 V / E3 / 60 Hz N/A 15A7060.3ME-EK76-WC 29A7061.3ME-EK76-WC 35A7062.3ME-EK76-WC 38A7063.3ME-EK100-WC 42A LP CompressorCapacity @ 175 psi 29 CFM · 821 L/min 29 CFM · 821 L/min 46 CFM · 1303 L/min 57 CFM · 1614 L/min 81 CFM · 2294 L/min 95 CFM · 2690 L/min Rated to Supply - FAD for 40% O2 - FAD for 36% O2 - FAD for 32% O2 10 CFM · 280 L
