JTAGjet-C2000 (Part No. JTAGjet-C2000F-ISO) is a small, palm-sized In-Circuit Debugging Probe for the TMS320C2000 family of DSPs from Texas Instruments. It is equipped with a USB 2.0 port that runs in the High-Speed mode at 480 Mb/sec. This emulator supports the following C2000 DSP devices: FAMILY SERIES MCU TMS320C24x Fixed-Point 16-bit TMS320F24x Fixed-Point 16-bit TMS320LC240x Fixed-Point 16-bit TMS320LF240x Fixed-Point 16-bit TMS320LF240x Fixed-Point 16-bit TMS320F2823x Fixed-Point 32-bit TMS320F2833x Fixed-Point 32-bit TMS320F28xx Fixed-Point 32-bit TMS320F2801x, 28044 Fixed-Point 32-bit TMS320F28xx Fixed-Point 32-bit TMS320F2802x Fixed-Point (PiccoloTM) 32-bit TMS320F2803x Fixed-Point (PiccoloTM) 32-bit TMS320F2833x Floating-Point (DelfinoTM)  32-bit TMS320C2834x Floating-Point (DelfinoTM)  32-bit Compatible with Code Composer Studio JTAGjet-C2000 is compatible with Code Composer Studio 3.3  up to 6.1 only. It installs directly into the Code Composer Studio directories and becomes visible as JTAGjet probein the CCStudio Setup utility and preconfigured with many C2000 targets. Setting up to work with JTAGjet is just as easy as setting up a TI emulator – just drag and drop the preconfigured target-and-emulator configuration and start CCStudio. JTAG Chain Device Detection For custom made boards with more than one device on the JTAG chain, JTAGjet can detect all devices on the chain which is necessary in to configure the CCStudio debugger. Variable JTAG Clock JTAGjet-C2000 supports variable JTAG clock. It defaults to 10 MHz, but may be set as low as 1 kHz (for slow FPGA prototypes or power saving devices) to 15 MHz to provide faster application downloads and quicker Flash programming. Hardware Features Supports TI TMS320C24xx and F28xx DSPs. USB 2.0 high-speed port (480 Mbps) provides faster downloads. Includes fully isolated JTAG adapter  (ADA_ISO_TI14_E). Supports all on-chip breakpo
